Type | SMD P5 | SMD P6 | SMD P8 | SMD P10 | ||||||||
Pixel pitch | 5mm | 6mm | 8mm | 10mm | ||||||||
Display area(mm) | 480x480 | 960x960 | 576x576 | 1152x1152 | 768x768 | 1536x1536 | 960x960 | 1920x1920 | ||||
Cabinet size(cm) | 52x90x7 | 100x141x12 | 62x99x7 | 120x160x12 | 82x120x12 | 160x200x12 | 102x134x12 | 198x236x12 | ||||
LED type | SMD2727 | SMD2727 | SMD3535 | SMD3535 | ||||||||
Resolution(dots) | 96x96 | 192x192 | 96x96 | 192x192 | 96x96 | 192x192 | 96x96 | 192x192 | ||||
Module size(mm) | 160x160 | 192x192 | 256x128 | 320x160 | ||||||||
Scan mode | 1/8scan | 1/8scan | 1/4scan | 1/2scan | ||||||||
Color | RGB | RGB | RGB | RGB | ||||||||
Net weight | 11kg | 32kg | 16kg | 40kg | 26kg | 70kg | 32kg | 120kg | ||||
Brightness | 5500nits | 5500nits | 6000nits | 6000nits | ||||||||
Refresh rate | ≥1920Hz | |||||||||||
Viewing angle | 120 deg.(H) 120 deg.(V) | |||||||||||
Max. power | 300W | 1200W | 300W | 1200W | 600W | 2000W | 600W | 2000W | ||||
Avg. power | 100W | 350W | 100W | 350W | 200W | 600W | 200W | 600W | ||||
Lifespan | 100000hours | |||||||||||
Working voltage | AC 220V±15%，50/60Hz | |||||||||||
Operation temperature | -20℃～+60℃ | |||||||||||
Operation humidity | 10%～90%RH | |||||||||||
Certification | CE/ROHS/FCC | |||||||||||
Type | SMD P5 | SMD P6 | SMD P8 | SMD P10 |
Pixel pitch | 5mm | 6mm | 8mm | 10mm |
Display area(mm) | 640x640 | 768x768 | 1024x1024 | 1280x1280 |
Cabinet size(cm) | 70x110x12 | 82x123x12 | 108x149x12 | 133x175x12 |
LED type | SMD2727 | SMD2727 | SMD3535 | SMD3535 |
Resolution(dots) | 128x128 | 128x128 | 128x128 | 128x128 |
Module size(mm) | 160x160 | 192x192 | 256x128 | 320x160 |
Scan mode | 1/8scan | 1/8scan | 1/4scan | 1/2scan |
Color | RGB | RGB | RGB | RGB |
Net weight | 22kg | 28kg | 34kg | 42kg |
Brightness | 5500nits | 5500nits | 6000nits | 6000nits |
Refresh rate | ≥1920Hz | |||
Viewing angle | 120 deg.(H) 120 deg.(V) | |||
Max. power | 900W | 900W | 1500W | 1500W |
Avg. power | 300W | 300W | 500W | 500W |
Lifespan | 100000hours | |||
Working voltage | AC 220V±15%，50/60Hz | |||
Operation temperature | -20℃～+60℃ | |||
Operation humidity | 10%～90%RH | |||
Certification | CE/ROHS/FCC | |||
Type | DIP P10 | DIP P10 | DIP P16 | DIP P20 |
Pixel pitch | 10mm | 10mm | 16mm | 20mm |
Display area(mm) | 960x960 | 960x960 | 768x768 | 960x960 |
Cabinet size(cm) | 102x135x12 | 102x135x12 | 82x120x12 | 102x135x12 |
LED type | DIP 346 | DIP 546 | DIP 546 | DIP 546 |
Resolution(dots) | 96x96 | 96x96 | 48x48 | 48x48 |
Module size(mm) | 320x160 | 320x160 | 256x256 | 320x160 |
Scan mode | 1/4scan | 1/4scan | 1/1scan | 1/1scan |
Color | RGB | Green | Green | Green |
Net weight | 40kg | 38kg | 31kg | 40kg |
Brightness | 8500nits | 7000nits | 7000nits | 7000nits |
Refresh rate | ≥1920Hz | |||
Viewing angle | 120 deg.(H) 70 deg.(V) | |||
Max. power | 600W | 600W | 300W | 300W |
Avg. power | 200W | 200W | 100W | 100W |
Lifespan | 100000hours | |||
Working voltage | AC 220V±15%，50/60Hz | |||
Operation temperature | -20℃～+60℃ | |||
Operation humidity | 10%～90%RH | |||
Certification | CE/ROHS/FCC | |||
