Various Pixels Pitch Available
Pixel pitch: 4mm/5mm/6.67mm/8mm/10mm/16mm. Standard cabinet size: 960mm x 960mm, Module size: 320mm x 320mm
Easy Maintenance
Module, PSU, control system both front and back service, two steps for module service. Screws Free & Rolling fast lock for fast assembly。
High Protection
Die-casting aluminium cabinet with high anti-corrosion, waterproof IP65/IP54 rating. Super High Stability.
Lightweight & Thin
Cabinet depth is only around 90mm. 15KG lighter compared to traditional steel cabinets.
High Brightness
High brightness up to 8000nits. Available for both SMD and DIP LED modules.
Flexible Use
Can be used as outdoor fixed installation advertising screen or stadium football screen.
Application
Module Number | PH4 | PH5 | PH6.67 |
Pixel Pitch | 4 mm | 5 mm | 6.67mm |
Led lamp | SMD1921 | SMD1921 | SMD2727 |
Physical Density | 62,500 pixels/m2 | 40,000 pixels/m2 | 22,500 pixels/m2 |
led Arrangement | 3 in 1SMD | 3 in 1SMD | 3 in 1SMD |
Module Resolution | 80x80pixels | 64x64pixels | 48x48pixels |
Module Dimensions | 320x320mm(12.60x1 2.60inch) | 320x320mm(12.60x1 2.60inch) | 320x320mm(12.60x1 2.60inch) |
Cabinet Resolution | 240x240pixels | 192x192pixels | 144x144pixels |
Cabinet Dimensions | 960x960x115mm(37. 80x37.80x4.53inch) | 960x960x115mm(37. 80x37.80x4.53inch) | 960x960x115mm(37. 80x37.80x4.53inch) |
Cabinet Weight | 30 kg | 30 kg | 30 kg |
Brightness | 5500-6500 nits | 5500-6500 nits | 5500-8000 nits |
Max Power
Consumption |
450w/panel |
450w/panel |
450w/panel |
Ave Power
Consumption |
150w/panel |
150w/panel |
150w/panel |
Viewing Angle | 160° (W) 160° (H) | 160° (W) 160° (H) | 160° (W) 160° (H) |
Operating Power
source | 110-240V AC
50-60Hz | 110-240V AC
50-60Hz | 110-240V AC
50-60Hz |
Operating | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C |
